Wall Mounted Ultrasonic Flow Meter Clamp Fixed Sewage Ultrasonic Flowmeter
Description of Wall Mounted Ultrasonic Flow Meter Clamp Fixed Sewage Ultrasonic Flowmeter
Wall Mounted Ultrasonic Flow Meter Clamp Fixed Sewage Ultrasonic Flowmeter is an ideal choice for measuring flow. Wall Mounted Ultrasonic Flow Meter Clamp Fixed Sewage Ultrasonic Flowmeter is battery-powered and uses a clamp-on transformer to measure the flow in the pipeline. Pipe diameters from 1/2" to 48" can be measured, and almost all pipes on the market can be measured. Wall mounted ultrasonic flow meter with display, it is convenient for users to set up. You only need to input pipe diameter, pipe wall thickness and pipe material to contact Beijing North Dahe Instruments and Meters to quickly measure.
Specification of Wall Mounted Ultrasonic Flow Meter Clamp Fixed Sewage Ultrasonic Flowmeter
| Item | Wall Mounted Ultrasonic Flow Meter Clamp Fixed Sewage Ultrasonic Flowmeter |
| Item | ultrasonic digital flow meter |
| Size(mm) | DN15mm---DN6000mm |
| Medium | Water, sea water, industrial sewage, acid and alkali, alcohol, beer, various oils, etc., a single uniform liquid that can conduct ultrasonic waves |
| Medium Temperature | -20~120C |
| Installation Type | Clamp fix type |
| OUtput | 4-20mA |
| Data communicaiton | RS232 Protocol Modbus protocol |
| Grade of Accuracy | 0.2%FS, 0.5%FS |
| Flow Velocity | v>0~±10m/s |
| Rated pressure | 1.6MPa |
| Pipe material | All dense pipes such as steel, stainless steel, cast iron, copper, PVC, aluminum, glass fiber reinforced plastic, etc. are allowed to be lined |
| Installation | Upstream 10D, downstream 5D, 30D away from pump outlet (D is pipe diameter) |
| Host temperature | -20~65C |
| Communication | RS485 Protocol Modbus protocol |
| Power Supply | 220VAC, 24VDC, battery |
| Protection | IP67 |
Detaild picture of Wall Mounted Ultrasonic Flow Meter Clamp Fixed Sewage Ultrasonic Flowmeter
Feature of Wall Mounted Ultrasonic Flow Meter Clamp Fixed Sewage Ultrasonic Flowmeter
Clamp-on transmitter is easy to install
No shutdown, no drilling, no pressure drop.
The built-in recorder can monitor the flow time at the same time.
Application of Wall Mounted Ultrasonic Flow Meter Clamp Fixed Sewage Ultrasonic Flowmeter
Wall Mounted Ultrasonic Flow Meter Clamp Fixed Sewage Ultrasonic Flowmeter is widely used in tap water, heating, water conservancy, metallurgy, chemical, machinery, energy and other industries. It can be used for production monitoring, flow verification, temporary detection, flow inspection, water meter balance debugging, heating network balance debugging, energy-saving monitoring, and it is an indispensable tool and meter for timely flow detection.
