Accurate and Durable YD36-3 Smart Water Pressure Sensor for Environmental Protection

Name: Accurate and Durable YD363 Smart Water Pressure Sensor for Environmental Protection
Brand: Clouds
Price: 50 USD

Accurate and Durable YD36-3 Smart Water Pressure Sensor for Environmental Protection Manufactures

Brand Name : Clouds

Model Number : YD36

Certification : CE

Place of Origin : China

MOQ : 1

Price : 50~70USD/PCS

Payment Terms : T/T, Western Union

Supply Ability : 100pcs per week

Delivery Time : 10 work days

Packaging Details : Carton Packaging

Storage Temperaturerange : -40℃~120℃

Size : 180 * 80 * 54mm (L * W * H)

Medium Temperature : -30 ~ 80 ℃

Power Supply Range : 24V ± 20%

Warranty : 1 year

Supply Voltage : 24VDC (Current / Voltage Output)

Contact Now

Description

The YD36-3 differential pressure transmitter is specifically designed for monitoring pressure or differential pressure in both industrial and OEM settings.

Employing imported chips and utilizing cutting-edge technology and processes, this transmitter excels in performance due to its circuit linearity and advanced temperature compensation techniques. Its compact size, stable structure, and lightweight design make it highly suitable for a wide range of applications.

This product is ideal for accurately measuring the pressure or differential pressure of various dry and non-corrosive gases. As a result, it finds widespread use in diverse fields such as electrical power, environmental protection, dust removal, textiles, leak detection, and numerous other applications.

Specififications

Parameter	YD36-3 Specification
Pressure Range	0-100Pa to 200KPa (max) or ±100Pa to ±200KPa
Accuracy	0.5% of Full Scale (F.S) typical; 0.25% of F.S (customized) optional
Working Temperature	-10℃ to 80℃ at 25℃ reference
Temperature Compensation	-10℃ to 80℃
Medium Compatibility	Dry and non-corrosive gases
Electrical Wires	2 Wires, 3 Wires, 4 Wires
Output Options	4-20mA, 0-5V, 0-10V, 0.5-4.5V, RS485 Modbus RTU
Power Supply	8-30V with potentiometer; 24-30V without potentiometer (for 4-20mA output); 5Vdc (specific to other outputs)
Electrical Connection	Fixed cable outlet
IP Rating	IP65
Pressure Connect Port	Φ8 gas port, Φ6 gas port, quick connector (optional)
Pressure Type	Differential pressure
Housing Materials	Aluminum

Features

Pressure sensitive
Digital temperature compensation
Imported chip assembled
Strong anti-humidity and water-resistance
IP65 enclosure
Advanced circuit linearity
Compact and easy to install

Accurate and Durable YD36-3 Smart Water Pressure Sensor for Environmental Protection

Accurate and Durable YD36-3 Smart Water Pressure Sensor for Environmental Protection Images
